Description
- Easy to install 4 ATO®/ATC® fused circuits
- Mounts on the battery terminal stud
- Screw terminals for securing wires
- Four Nylon insulated ring terminals included
- Insulating cover included
- Accepts Small Format Circuit Labels
- Includes 1 fuse
| Specifications | |
|---|---|
| Circuits | 4 |
Maximum Amperage  | 100A per block 30A per circuit |
| Maximum Voltage | 32V DC |
| Mounting | Clearance for 3/8" [M10] stud |
| Screw Terminal Torque | 18 in-lb (2.03 Nm) |
| Screw Terminal Type | #8-32 Screws with captive star lock washer |
| Weight | 0.25lb (0.11 kg) |
| Shipping Dimensions | 20L x 10cm W x 5cm H |
| Meets the following Regulatory Specifications |
|---|
    |
